VALVES CATALOGUE

Safety valve with conical threading M8.15x0.75 , opening from 2 to 3 bar and external key 11, Teflon sealing -

2135

Technical details

  • PRESSURE : 2,5±0,5
  • FITTING : conical M8,15x0,75
  • BODY MATERIAL : CW614N
  • SEAL MATERIAL : Teflon®
  • FLUID PASSAGE SECTION MM2 : 6.5

Download complete Data Sheet

Do you want to download the complete product data sheet in PDF format?

Fill out the form below to download product Datasheet. The data collected will be used to contact you if you need to receive more information about our products.

To help us avoid spam, please enter the result of this operation in the box below: =

I declare to be informed in accordance with current European legislation (EU Regulation 2016/679) as well as the Italian law (Legislative Decree No. 196/2003 and subsequent amendments) and to accept the privacy policy.



Description: Safety valve with conical threading M8.15x0.75 , opening from 2 to 3 bar and external key 11, PTFE sealing -
Suitable for: various
Minimum order quantity: 2500
Disponibility in shop: 4 Week from order
AQL=0,65 on precision of opening point AQL=0,65 on sealing
AQL=0,65 on threading
Respects rules:

• RoHS European directive 2002/95/EC -2015/863/EC on use of certain hazardous substances.
• Reach regulation (EC 1907/2006 – 1272/2008) et enclosed XVIII 26 June 2009 and list SVHC up-to date at 19/12/2018.
Note: Available for uses until 250 °C


SIMILAR PRODUCTS :


Safety valve 4 Bar with 1/8 Gas, Hex key 11, sealing by Teflon® Ball and external gasket in Viton®

Safety valve 1 Bar with 1/8 Gas, Hex key 11, sealing in Teflon® and external gasket in Viton®

Valve 0,75 Bar with 1/8 Gas, Hex key 15, sealing in Teflon® and external gasket in Viton®
