VALVES CATALOGUE

Safety valve with cylindrical threading M9.1x0.75 , opening fromn 3 to 4,5 bar and external key 11 - 100% tested

3166

Technical details

  • PRESSURE : 3,75±0,75
  • FITTING : conical M9,1x0,75
  • BODY MATERIAL : CW614N Nichel Plated
  • SEAL MATERIAL : Silicone
  • FLUID PASSAGE SECTION MM2 : 8.6

Download complete Data Sheet

Do you want to download the complete product data sheet in PDF format?

Fill out the form below to download product Datasheet. The data collected will be used to contact you if you need to receive more information about our products.

To help us avoid spam, please enter the result of this operation in the box below: =

I declare to be informed in accordance with current European legislation (EU Regulation 2016/679) as well as the Italian law (Legislative Decree No. 196/2003 and subsequent amendments) and to accept the privacy policy.



Description: Safety valve with cylindrical threading M9.1x0.75 , opening fromn 3 to 4,5 bar and external key 11 - 100% tested
Suitable for: Not available on coffee maker due to a international patent.
Other tecnical uses all avaialble.
Minimum order quantity: 3000
Disponibility in shop: Available
AQL=0,4 on precision of opening point
Respects rules: • RoHS European directive 2002/95/EC -2015/863/EC on use of certain hazardous substances.
• Reach regulation (EC 1907/2006 – 1272/2008) et enclosed XVIII 26 June 2009 and list SVHC up-to date at 19/12/2018.
Note:
