VALVES CATALOGUE

Venting Valve , M8x0,75 Hex Key 12 adjustable 1,5-5,5 Bar and ring for operate

2930

Technical details

  • PRESSURE : 3,5±2 adjustable
  • FITTING : cylindrical M8x0,75
  • BODY MATERIAL : CW614N Nichel Plated
  • SEAL MATERIAL : Silicone
  • FLUID PASSAGE SECTION MM2 : 17.2

Download complete Data Sheet

Do you want to download the complete product data sheet in PDF format?

Fill out the form below to download product Datasheet. The data collected will be used to contact you if you need to receive more information about our products.

To help us avoid spam, please enter the result of this operation in the box below: =

I declare to be informed in accordance with current European legislation (EU Regulation 2016/679) as well as the Italian law (Legislative Decree No. 196/2003 and subsequent amendments) and to accept the privacy policy.



Description: Venting Valve , M8x0,75 Hex Key 12 adjustable 1,5-5,5 Bar and ring for finger operation
Suitable for: Food processing, carbonators, modelling, general purposes.
Minimum order quantity: 1500
Disponibility in shop: On request
AQL=1 on precision of opening point
Respects rules: • RoHS European directive 2002/95/EC -2015/863/EC on use of certain hazardous substances.
• Reach regulation (EC 1907/2006 – 1272/2008) et enclosed XVIII 26 June 2009 and list SVHC up-to date at 19/12/2018.
Note: adjustable with small stright nose pliers
