2234

Technical details

PRESSURE : 3,75±0,75
FITTING : cylindrical M8x0,75
BODY MATERIAL : CW614N Nichel Plated
SEAL MATERIAL : Silicone
FLUID PASSAGE SECTION MM2 : 5.9

Download complete Data Sheet

Do you want to download the complete product data sheet in PDF format?

Fill out the form below to download product Datasheet. The data collected will be used to contact you if you need to receive more information about our products.

To help us avoid spam, please enter the result of this operation in the box below: 8 + 6 =

I declare to be informed in accordance with current European legislation (EU Regulation 2016/679) as well as the Italian law (Legislative Decree No. 196/2003 and subsequent amendments) and to accept the privacy policy.

Description: Safety Valve for aluminium coffee maker M8x0.75 - 3- 4.5 Bar
Suitable for: Coffee makers, similar appliances.
Minimum order quantity: 5000
Disponibility in shop: 4 week from order
AQL=0,65 on precision of opening point
Respects rules: • RoHS European directive 2002/95/EC -2015/863/EC on use of certain hazardous substances.
• Reach regulation (EC 1907/2006 – 1272/2008) et enclosed XVIII 26 June 2009 and list SVHC up-to date at 19/12/2018.
