Valve M8x0.75 Ch9 pressure 7-9 Bar

1157

Technical details

  • PRESSURE : 8±1
  • FITTING : cylindrical M8x0,75
  • BODY MATERIAL : CW614N
  • SEAL MATERIAL : AISI 420C on Brass seat
  • FLUID PASSAGE SECTION MM2 : 4.3


Description: Valve M8x0.75 Ch9 pressure 7-9 Bar
Suitable for: Home appliances, pressure vessels.
Minimum order quantity: 5000
Disponibility in shop: 4 Week from order
AQL=1 on precision of opening point
Respects rules:

• RoHS European directive 2002/95/EC -2015/863/EC on use of certain hazardous substances.
