VALVES CATALOGUE

Check valve with treading 1/8 Gas and hose connection 6x8

1013

Technical details

  • PRESSURE : 0,25±0,05
  • FITTING : 1/8 R ISO-7 conical
  • BODY MATERIAL : CW510L
  • SEAL MATERIAL : Silicone
  • FLUID PASSAGE SECTION MM2 : 20

Download complete Data Sheet

Do you want to download the complete product data sheet in PDF format?

Fill out the form below to download product Datasheet. The data collected will be used to contact you if you need to receive more information about our products.

To help us avoid spam, please enter the result of this operation in the box below: =

I declare to be informed in accordance with current European legislation (EU Regulation 2016/679) as well as the Italian law (Legislative Decree No. 196/2003 and subsequent amendments) and to accept the privacy policy.



Description: Check valve with treading 1/8 Gas and hose connection 6x4
Suitable for: Professional and domestic coffee machines, instant brewing, ecc.
Minimum order quantity: 500
Disponibility in shop: 4 Week from order
AQL=0,4 on precision of opening point
Respects rules: • RoHS European directive 2002/95/EC -2015/863/EC on use of certain hazardous substances.
• Reach regulation (EC 1907/2006 – 1272/2008) et enclosed XVIII 26 June 2009 and list SVHC up-to date at 19/12/2018.
Note: Cap on tube side is optional item #1020 in CW614N


SIMILAR PRODUCTS :


Code 4421

Check valve with two treading 1/8 Gas male LEAD FREE with content of lead less 0,2%

Code 1735

Check valve with treading 1/8 Gas male and female
