VALVES CATALOGUE

Venting valve with 6 lateral holes Threading M8x0.75 hex key 9

0990

Technical details

  • PRESSURE : 3,75±0,75
  • FITTING : cylindrical M8x0,75
  • BODY MATERIAL : CW614N
  • SEAL MATERIAL : AISI 420C on Brass seat
  • FLUID PASSAGE SECTION MM2 : 4.6

Download complete Data Sheet

Do you want to download the complete product data sheet in PDF format?

Fill out the form below to download product Datasheet. The data collected will be used to contact you if you need to receive more information about our products.

To help us avoid spam, please enter the result of this operation in the box below: =

I declare to be informed in accordance with current European legislation (EU Regulation 2016/679) as well as the Italian law (Legislative Decree No. 196/2003 and subsequent amendments) and to accept the privacy policy.



Description: Venting valve with 6 lateral holes Threading M8x0.75 hex key 9
Suitable for: Professional and domestic coffee machines, instant brewing, ecc.
Minimum order quantity: 1500
Disponibility in shop: On request
AQL=1 on precision of opening point
Respects rules: • RoHS European directive 2002/95/EC -2015/863/EC on use of certain hazardous substances.

Note: six radial hole to distribute regulated fluid
