VALVES CATALOGUE

Valve with threading 1/8 Gas, 4 Bar NBR sealing

0560

Technical details

  • PRESSURE : 4,0±0,5
  • FITTING : 1/8 Gas ISO228 cylindrical
  • BODY MATERIAL : CW614N Nichel Plated
  • SEAL MATERIAL : NBR
  • FLUID PASSAGE SECTION MM2 : 12


Description: Valve with threading 1/8 Gas, 4 bar opening
Suitable for: Home appliances, pressure vessels, oleodinamics
Minimum order quantity: 500
Disponibility in shop: On request
AQL=0,65 on precision of opening point
Respects rules: • RoHS European directive 2002/95/EC -2015/863/EC on use of certain hazardous substances.
• Reach regulation (EC 1907/2006 – 1272/2008) et enclosed XVIII 26 June 2009 and list SVHC up-to date at 19/12/2018.
Note: max temperature 90 °C
