VALVES CATALOGUE

Safety Valve for coffee maker M8x0.75 Key 9 with threading initial step Ø7

0510

Technical details

  • PRESSURE : 4±1,5
  • FITTING : cylindrical M8x0,75
  • BODY MATERIAL : CW614N
  • SEAL MATERIAL : AISI 420C on Brass seat
  • FLUID PASSAGE SECTION MM2 : 4.6


Description: Safety Valve for coffee maker M8x0.75 Key 9 with threading initial step Ø7
Suitable for: Cast aluminium coffee makers.
Minimum order quantity: 10000
Disponibility in shop: On request
AQL=1 on precision of opening point
Respects rules: • RoHS European directive 2002/95/EC -2015/863/EC on use of certain hazardous substances.
• Reach regulation (EC 1907/2006 – 1272/2008) et enclosed XVIII 26 June 2009 and list SVHC up-to date at 19/12/2018.
Note:
