VALVES CATALOGUE

Nickel Plated Safety Valve for Stainless Steel coffee maker M8.15x0.75 Key 9

0003G

Technical details

  • PRESSURE : 4,0±1,5
  • FITTING : conical M8,15x0,75
  • BODY MATERIAL : CW614N Nichel Plated
  • SEAL MATERIAL : AISI 420C on Brass seat
  • FLUID PASSAGE SECTION MM2 : 4.6

Download complete Data Sheet

Do you want to download the complete product data sheet in PDF format?

Fill out the form below to download product Datasheet. The data collected will be used to contact you if you need to receive more information about our products.

To help us avoid spam, please enter the result of this operation in the box below: =

I declare to be informed in accordance with current European legislation (EU Regulation 2016/679) as well as the Italian law (Legislative Decree No. 196/2003 and subsequent amendments) and to accept the privacy policy.



Description: Nickel Plated Safety Valve for Stainless Steel coffee macker M8.15x0.75 Key 9
Suitable for: Stainless steel coffee makers made by sheet deep drawing.
Minimum order quantity: 10000
Disponibility in shop: 2 Week from order
AQL=1 on precision of opening point
Respects rules:

• RoHS European directive 2002/95/EC -2015/863/EC on use of certain hazardous substances.
• Reach regulation (EC 1907/2006 – 1272/2008) et enclosed XVIII 26 June 2009 and list SVHC up-to date at 19/12/2018.
Note:


SIMILAR PRODUCTS :


Code 0003

Safety Valve for Stainless Steel coffee macker M8.15x0.75 Key 9

Code 0001

Standard Safety Valve for aluminium coffee maker M8x0.75 key 9

Code 0006

Safety valve made in AISI430F for coffee maker M8x0.75 Key 9 TESTED 100%
